Temperature sensor TP-383
Product description
Sensor for measuring the temperature of windings of electric motors.
Technical data
| Temperature range | –40÷150°C |
| Measuring element | platinum resistor (Pt100) (1) |
| Measuring element class | B (1) |
| Maximum operating current | 2 mA |
| Response time T0.9 | 5 s |
| sensor cable | 2×0.5mm in fiber glass insulation (1) |
(1) Other parameters according to customer requirements
