sensor heads
Product description
Heads for temperature sensors
Technical data
| Type | Material | Connection D | Gland G | IP class | Designation |
|---|---|---|---|---|---|
| AA | aluminum RAL9006 | Ø32,5 | P16 | IP 54 | AA-32 |
| BA | aluminum RAL9006 | M24x1,5 | P16 | IP 54 | BA-M24 |
| BEG | stainless steel SS316 | M24x1,5 | M20x1,5 | IP 65 | BEG |
| BEGe | stainless steel SS316 | M24x1,5 | M20x1,5 | IP 54 | BEGe |
| Typ DAA | aluminum RAL9006 | Ø32,5 | P16 | IP 54 | DAA-32 |
| DANA | aluminum RAL9006 | M24x1,5 | M20x1.5 | IP 54 | DANA-M24 |
| DANAW | aluminum RAL9006 | M24x1,5 | M20x1,5 | IP 54 | DANAW-M24 |
| DNAG | aluminum RAL9006 | G1/2” | M20x1,5 | IP 65 | DNAG-G |
| MAA | aluminum RAL9006 | M10x1 | P9 | IP 54 | MAA-M10 |
| MAA | aluminum RAL9006 | M12x1 | P9 | IP 54 | MAA-M12 |
| NS | polyphenylene oxide black | M20x1,5 | P16 | IP 54 | NS-M20 |
| NS | polyphenylene oxide black | M24x1,5 | P16 | IP 54 | NS-M24 |
| TL | aluminum RAL9006 | G1/2” | IP 00 | TL | |
| TS | aluminum RAL9006 | G1/4” | IP 00 | TS |
